End-of-shaft Inductive eMotor Rotor Position Sensor
Accurate feedback on the angular position, direction, and speed of the rotor shaft is essential to optimize control of the motor inverter and drive the electric engine with the best possible efficiency. With lower weight, smaller dimensions, immunity to stray fields and comparably lower cost, Inductive eMotor Rotor Position Sensors offer a true alternative to conventional resolvers. The possibility to perfectly customize the sensor to the motor dimensions enables more flexibility in the development of the electric / hybrid powertrain of the future.
Inductive sensors use the physical principle of induction in a wire loop and eddy currents to detect the position of a solid metallic target rotating above a set of coils. This allows a reduction in parts and higher design flexibility (e.g. through-shaft, end-of-shaft and arc configurations). Furthermore, inductive eMotor rotary position sensors can be designed to be ASIL-D compliant on sensor level.
End-of-shaft sensor available for testing
The PSCI eMotor Rotor Position Sensor can be mounted on the same shaft as the electric machine rotor, is immune to electromagnetic stray fields and provides accurate measurement of rotor position in a compact, light weight and fully sealed package.
KEY FEATURES
SPECIFICATIONS
Signal output |
Single-ended demodulated sine/cosine (1.0V to 4.0V) Differential demodulated sine/cosine (-3V to +3V) |
Accuracy | ±1°el |
Resolution | infinite |
Propagation delay | <4.2 μsec |
Supply voltage | 5V ±10% |
Supply current | Max 15mA |
Voltage protection | ±18 V |
Maximum electrical speed | 600.000 rpm |
Other technical specifications available. Contact [email protected]
Max. speed (mec) |
200.000 rpm (6-pole version) 150.000 rpm (8-pole version) 100.000 rpm (12-pole version) |
Mounting torque | Max 2.2 N m |
Target material | Conductive metal |
Other technical specifications available. Contact [email protected]
Operating temperature | -40°C to +150°C (coil temperature can be > 150°C) |
Sealing | IP69K |
Other technical specifications available. Contact [email protected]
