N-6R
6-mm miniature carbon SMD reflow potentiometer
The N-6R is a unique, fully RoHS & REACH ready Miniature Control Potentiometer with all the features of traditional full size potentiometers. The combination of wide electrical angle, ROHS reflow capability, reduced form factor, tape on reel packaging for automated high speed placement and extra long mechanical life provides market leading performance in a compact & robust design.
The N-6R has been conceived for the Industrial, Automotive and Appliance markets to provide a cost effective control solution. Further options include improved linearity and standard shaft and knobs.
■ Up to 10k cycles mechanical life
■ Over-moulding manufacturing technique
■ Embossed Tape (for SMD) packaging for automatic insertion or bulk for manual assembly
■ Both sides cross slot easy adjustment
■ Accidental rotor movement protected
■ IP54 protection according to IEC 60529
SPECIFICATIONS
Taper | Linear |
Range of values* |
(Decad. 1.0 - 2.0 - 2.2 - 2.5 - 4.7 - 5.0) Standard version - 250Ω ≤ Rn ≤ 500KΩ Long-life version - 1KΩ ≤ Rn ≤ 500KΩ |
Tolerance* | ± 30% |
Max. Voltage | 100 VDC |
Nominal power 50°C (122°F) | 0.1 W |
Residual resistance | ≤ 2% Rn (10Ω min.) |
Equivalent noise resistance | ≤ 5% Rn |
Operating temperature ** |
-25°C to +70°C (-13°F to + 158°F) |
* Others available on request ** Up to 85°C depending on application.
Mechanical rotation angle | 280° ± 10° |
Electrical rotation angle | 245° ± 25° |
Torque |
Rotational - 0.2 to 3 Ncm (0.28 to 4.2 in-oz) Stop - > 7.5 Ncm (>10.5 in-oz) |
Life | Up to 10.000 cycles |
Endless rotation upon request
Test conditions (CEI 393-1) | ΔR - Typical test results | |
---|---|---|
Electrical life | 1.000h at 50°C; 0.1 W | ±5% |
Mechanical life |
Standard version: 100 cycles at 10 to15 cpm
Long-life version: 10.000 cycles at 10 to15 cpm |
±3 % (Rn < 1M Ω) ±4 % (Rn < 1M Ω) |
Temperature coefficient | –25° C; +70° C | ±300 ppm/°C (Rn ≤100K) |
Thermal cycling | 16h at 85°C and 2h at -25°C | ±2.5% |
Damp heat | 500h at 40°C and 95% relative humidity (RH) | ±5% |
Vibration | 2h each plane at 10Hz - 55Hz | ±2% |
Storage | 6 month at 23°C ±2°C and 50% RH | ±2.5% |
Out of range values may not comply with these results. Standard test conditions: temperature:23°C ±2°C and 45% to 70% RH
