PS-10

10mm carbon SMD potentiometer

The PS-10 SMD potentiometer offers control where frequent adjustment is required. The shaftless design allows for employment of different engagement mechanisms, such as a customized shaft, a motor control or a human interface adjustment. This potentiometer can also control variable outputs including frequency, change in motor speed or volume

  ■  Up to 10.000 life cycles
  ■  IP54 protection
  ■  Embossed tape packaging according to IEC 60286-3:2007
  ■  Wiper positioned at initial, 50% or fully clockwise
  ■  Self extinguishable plastic (UL 94V-0) available
  ■  Up to 16 mechanical detents for tactile feedback
  ■  Locating pins for accurate PCB positioning
  ■  Low torque version available
  ■  Shafts and knobs


KEY FEATURES



SPECIFICATIONS

Taper¹ Linear
Range of values¹ 1KΩ ≤ Rn ≤ 1MΩ
Max. Voltage 200 VDC
Nominal power 0.15 W @ 50°C (122°F)
Residual resistance¹ ≤ 0.5% Rn (5Ω min.)
Equivalent noise resistance ≤ 3% Rn (3Ω min.)
Operating temperature¹ -40°C to +85°C
(-13°F to + 158°F)

1 Others available on request

Mechanical rotation angle 235° ± 5°
Electrical rotation angle 220° ± 20°
Torque Rotational: 0.4 to 2 Ncm (0.6 to 2.7 in-oz)
Stop: > 5 Ncm (>7 in-oz)
Life1 Up to 10k cycles

1 Others check availability

Test method (CEI 393-1) ΔR(%)- typical test results
Electrical life 1.000h at 50°C; 0.15W ±10%
Mechanical life 1000 cycles at 10 to 15 cpm ±10%
Temperature coefficient -40°C; +85°C
-25°C; +70°C 		±1.500 ppm/°C
±1.000 ppm/°C
Thermal cycling 16h at 90°C and 2h at -40°C ±5%
Damp heat 500h at 40°C and 95% relative humidity (RH) ±15%
Vibration 2h each plane at 10Hz - 55Hz ±3%
Storage 6 months at 23°C ±2°C and 50% RH ±5%

Out of range values may not comply with these results. Standard test conditions: temperature:23°C ±2°C and 45% to 70% RH
