HCSO-1W
Automotive Open Loop Hall Effect Current Sensor
Piher Sensing Systems’ HCSO-1W family of open-loop Hall-effect current sensors delivers accurate, non-intrusive current measurement with galvanic isolation between power and control to enhance safety and reduce energy loss. Its ratiometric 0.5–4.5 V analog output makes ECU integration straightforward, and options for simple or redundant channels—including dual-range versions that cover both low and high currents (±25 A to ±1000 A)—let one platform scale across multiple designs. Flanged, wire-through mounting speeds installation and keeps insertion losses minimal. Built to stay precise from −40 °C to +125 °C and resist external magnetic interference, it delivers reliable measurements in harsh automotive and industrial environments.
Typical uses include BMS current measurement across EV/HEV/PHEV/BEV platforms, leakage detection and fault isolation in charging systems, current measurement in energy storage systems, and fault detection in heavy industrial equipment.
■ Open-loop current sensor based on Hall effect.
■ Dual-channel sensor for high and low currents (two ranges).
■ Flanged, cable/wire-through-hole. Busbar.
■ Simple or redundant analog ratiometric output
■ Galvanic isolation between power supply and control.
■ Measured current range from ±25 A to ±1000 A.
■ Non-invasive technology.
■ Operating temperature from -40°C to +125°C
■ Designed to be durable for use in transportation settings
KEY FEATURES
SPECIFICATIONS
| Parameter | Unit |
|---|---|
| Supply voltage | 5 V ±10% |
| Current consumption | Typ. 26 mA |
| analog output | 0.5 V to 4.5 V |
| Overvoltage protection | +10 V |
| Creepage distance | 3.95 mm |
| Clearance | 3.95 mm |
| Connector | TYCO 1-1564559-1 |
| Max. mounting torque | 2.5 N.m (M4x, 7mm) |
| Parameter | Unit |
|---|---|
| Operating temperature | -40°C to +125°C |
| IP-Rating | IP67 / IP69K (not considering connector) |
POTENTIAL APPLICATIONS
