NPL
Contacting linear position sensor / Slide Potentiometer
Provides a cost-efficient, highly reliable solution for slider potentiometer and linear position sensing applications:
- Automotive seat position memory
- HVAC sensor
- Central locking
- Headlamp levelling position and rear-view mirror position sensors
- Front and rear load angle sensor used to measure the angle of car head lights.
Main features
- 7,25mm, 8mm or 12mm travel
- High reliability
- Simple construction (only 3 component parts)
- Over-moulding manufacturing technique
- Plastic or metal clip versions available
- Various fixation means: clip type (inward/outward actuating), locating pins,…
SPECIFICATIONS
Range of values | 1K to 100K ohms |
Tolerance | ± 30% |
Max. voltage* | 50 VDC to 100 VDC |
Power rating* | 0.20 W @ 50°C |
Operating temperature | -40°C to +105°C |
Taper** | Linear |
Relative linearity** | ± 2% |
Mechanical Life | 50K cycles |
* Depending on model ** Others check availability
Mechanical travel |
NPL07 - 7,25mm NPL08 - 8mm NPL12 - 12mm |
Electrical travel | (see how to order) |
Sliding force | ≤2N @ 10mm/sec |
Stop strenght | 30N for 5 secs |
APPLICATION EXAMPLES
