PSAI

Inductive Rotary Arc Position Sensor

Piher Sensing Systems’ Inductive Arc Position Sensors are conceived for heavy-duty applications such as tractors, excavators and loaders. Inductive sensors do not depend on magnets, but detect the position of a solid metallic target that can easily be integrated into the existing machinery structure.
In addition to the sensors’ excellent accuracy, IP67 and IP69K sealing and high temperature tolerance make these absolute position sensors an excellent choice for harsh environments typically found in off-highway applications.
The arc design enables a simple and fast assembly and calibration process at the manufacturing line, leading to additional cost savings during the production process.






KEY FEATURES

Without any internal or external gears or linkages the sensor is easily assembled and calibrated and free from wear and tear over lifetime.
No shielding required as inductive technology is not affected by electromagnetic stray fields.
The separation of electronics and magnet module allows for a virtually unlimited lifetime independent of number of revolutions.

The sensor target can be integrated into the existing application, and the sensor itself comes in an exceptionally compact and low profile package.

The rugged package protects the sensor from dust, moisture, vibration and extreme temperatures for usage in the most demanding environments.

Custom mechanical design, programmable transfer function and switch outputs as well as different output protocols and redundancy levels available.



SPECIFICATIONS

Parameter Low voltage High voltage
Linearity* ±1% absolute (up to ±0.5% on request)
Angular range* 150°
100°
45°
Output protocols** Analog (ratiometric)
PWM
SENT
CAN Open / CAN SAE J1939
Output function* Standard
Inverted
Redundant 		10% to 90% Vdc (CW)
90% to 10% Vdc (CCW)
10% to 90% Vdc (CW and CCW)
Start-up time <10ms
Resolution Analog, PWM
SENT, CAN 		up to 10 bit
up to 12 bit
Max. output rate (updates per second) Analog ramp
PWM
SENT
CAN 		10000
2000
1235
10
Supply voltage 5V ±10% 7V to 32V
Typical current consumption Simple
Redundant
CAN 		12 mA
24 mA
68mA 		14 mA
28 mA
72mA
Voltage protection ±10V ±36V
Self-diagnostic features yes

* Other specifications on request.
** CAN protocol available for simple output versions only.

Rotational life Virtually unlimited
Air gap 2mm ±1mm between sensor and target
Operating and storage temperature -40°C to +125°C
Shock 50g
Vibration 5-2000 Hz; 20g; Amax 0,75 mm
Sealing IP67, IP69K


APPLICATION EXAMPLES
