MTS-360

Rotary Through-Shaft Miniature Hall-Effect Position Sensor

The MTS-360 provides a true breakthrough in contactless sensor technology by combining a
through-shaft design with 360º absolute position feedback in an ultra miniature size. The result is the smallest fully featured rotary sensor on the market with reliability up to 50 million cycles.
With its tiny size, engineers can now integrate a fully featured rotary sensor directly on their PCB without the packaging issues that typically accompany encoders or other absolute position devices. The exceptionally low profile fits easily in places that were previously too small for pre-packaged rotary sensors.
The MTS-360 PCB package enables time and cost savings by easily mounting a fully featured rotary sensor including connector without the need to design a printed circuit board for the sensor.

KEY FEATURES

Contactless Operation

Without any gears or mechanical interfaces the sensor is easily assembled and calibrated and subject to limited wear and tear over lifetime.

Fits in the smallest of spaces

With a footprint of less than 18 x 18mm, height of 5.9mm and less than 3g this rotary sensor can be used in even the most space-constraint application.

Through-hole design

Allows shaft insertion from top or bottom, simple assembly and makes it even more suitable in applications where space is limited.

360 degree absolute position feedback

Endless mechanical rotational angle without dead band, keeps the position on power loss with programmable electrical angles from 15 to 360 degrees.

Durable and robust design

The non-contacting design allows for an extra-long product lifetime of up to 50 million cycles.

Adaptable to your requirements

Programmable transfer function and switch outputs as well as different output protocols and redundancy levels available

SPECIFICATIONS

Linearity* **	±1% absolute (±0.5% upon request)
Electrical angular range*	Programmable from 15° to 360°
Output protocols	Analog (Ratiometric), PWM Serial Protocol (SPI)
Output	Simple Redundant Full-redundant (on request)
Switch output	Yes, programmable
Switch accuracy*	±3°
Resolution	Analog, PWM Up to 12 bit SPIUp to 14 bit
Supply voltage*	5V ±10%
Supply current	Single version Typ 8.5 mA Redundant version Typ 17 mA
Voltage protection	+20V / -10V
Self-diagnostic features	yes

1 Other specifications available
2 Ferromagnetic materials close to the sensor (i.e. mounting surface) may affect the sensor’s linearity.

Rotational life	Up to 50.000.000 cycles
Mechanical range	360° (endless rotation)

Model	MTS-360	MTS-360PCB
Operating and storage temperature*	-40° to +125°C	with connector: -40° to +105°C without connector: -40° to +125°C
Shock	50g
Vibration	5-2000 Hz; 20g; Amax 0,75 mm
Sealing*	IP50
